No

Kod

Parça Adı

1

122719

Differential housing

2

121606

Lateral cover

3

13543424

STUD BOLT

27

14040711

NUT

28

12601374

Washer

6

125076

Sealing ring

7

122153

Seating ring

8

13449624

Stud securing crankcase to gearbox

9

13550321

WASHER

10

13449824

Stud

11

13450021

Stud

12

133988

NUT

38

127497

Washer

14

11500024

Stud for cover of flywheel

15

14039614

NUT

16

11197774

Washer

17

122047

Ditto, thickness mm. 2,7

17

122048

Ditto, thickness mm. 2,9

17

122045

Ditto, thickness mm. 3,1

17

122046

Ditto, thickness mm. 3,3

17

122044

Spacer for differential cover thickness mm. 2,5 (eventual use)

18

104280

Oil drain Plug

19

10263460

Gasket

20

14326050

CAP

21

65928500

THREADED PLUG

22

14326007

Plug

23

10260160

GASKET

24

117812

Bush

25

121929

Ring

26

13543524

STUD BOLT

29

13543624

STUD BOLT

30

122773

Tube

31

113664

Breather

32

14330260

Gasket

33

10116501

Clamp

34

122070

Ditto, thickness mm. 3

34

122071

Ditto, thickness mm. 3,20

34

122068

Ditto, thickness mm. 3,40

34

122069

Ditto, thickness mm. 3,60

34

122067

Spacer for differential bearing thickness mm. 2,80 (eventual use)

35

13526070

Heli-coil securing cover

36

13525870

THREADED INSERT

37

11234721

SCREW

39

126290

Screw

40

126289

Screw
