No

Kod

Parça Adı

-

147181

L.H. CENTRAL AIR INLET PIPE

-

147180

LH FRONT-REAR AIR INLET PIPE

1

10261460

Gasket

2

121718

UNION

3

141195

PIPE FOR AIR INLET

28

148494

SECONDARY AIR VALVE

30

13000490

Screw Collar

6

133962

AIR INLET SLEEVE

27

150595

BLIND NUT

8

147390

CUT-OFF VALVE

9

116785

PIPE FROM CUT-OFF TO AIR INLET

14

115676

PIPE FROM CUT-OFF TO SOLENOID VALVE

11

121793

3-WAY UNION

12

115147

RUBBER PIPE

13

140175

DEPRESSION TANK

15

141235

RUBBER PIPE

16

111704

SOLENOID VALVE

17

124346

RUBBER PIPE

18

11500024

Stud for cover of flywheel

19

10519424

WASHER

22

14039614

NUT

21

14499370

Washer

23

145702

CLIP

24

10418301

Clamp (Ø 8 mm)

25

147178

RH FRONT-REAR AIR INLET PIPE

26

147179

R.H. CENTRAL AIR INLET PIPE

29

147360

AIR INLET SLEEVE
