No

Kod

Parça Adı

-

646126

R.H. SEAT COMPLETE

-

64490900

R.H. SEAT HOOK LEVER

-

64491800

R.H. SEAT TOOTHED WHEEL

-

64275400

SCREW mm. 32

-

63998500

R.H. HANDLE FOR SEAT RELEASE

-

62955700

CLAMP FOR R.H.SEAT BACK

-

64601600

RH CUSHION-SEAT BACK CONNECTING INNER PLATE

-

62739100

RH DEVICE FOR BACK SEAT ADJUSTMENT

-

64980500

SAFETY BELTS

-

63970600

R.H. SEAT BACK BELT-SLIDING

-

64601800

RH CUSHION-SEAT BACK CONNECTING INNER PLATE

-

652955

L.H. LINING

-

63997500

RH SAFETY BELT SLIDE STRUCTURE

-

652952

RH SAFETY BELT SLIDE STRUCTURE

-

652954

R.H. LINING

-

642381

RH SAFETY BELT SLIDE COVERING

-

642382

SLIDE COVERING UPHOLSTERY

-

652953

LH SAFETY BELT SLIDE STRUCTURE

-

642370

LH OUTER GUARDING STRUCTURE UPHOLSTERY

-

642363

COVERED RH SEAT BACK OUTER GUARDING STRUCTURE

-

642364

RH OUTER GUARDING STRUCTURE UPHOLSTERY

-

642159

LH INNER GUARDING STRUCTURE UPHOLSTERY

-

642136

COVERED RH SEAT BACK INNER GUARDING STRUCTURE

-

639202

SEAT BACK BULKHEAD UPHOLSTERY

-

635485

SEAT BACK REAR POCKET UPHOLSTERY

-

642366

RH CUSHION INNER COVERING

-

642368

RH CUSHION OUTER COVERING

-

636463

RH SEAT BACK OUTER COVERING

-

648488

HEAD-REST UPHOLSTERY

-

636460

RH SEAT BACK INNER COVERING

-

635873

CUSHION CENTRAL PADDING

-

646127

L.H. SEAT COMPLETE

1

636456

COMPLETE SEAT BACK UPHOLSTERY

2

635858

COMPLETE SEAT CUSHION

3

639935

COVERED CUSHION CENTRAL PADDING

4

647622

UPHOLSTERED HEAD-REST

5

20058905

BUSHINGS FOR HEAD-REST

6

636486

LH SEAT BACK INNER COVERING

7

636488

LH SEAT BACK OUTER COVERING

8

63379100

FIXING BUTTON

9

63945000

BRACKET

14

20297602

Screw -Valid for CDN, SA, J-

60

64314400

SCREW mm. 19

12

642389

LH CUSHION INNER COVERING

13

642390

LH CUSHION OUTER COVERING

15

636459

REAR BULKHEAD ASSEMBLY FOR SEAT BACK

16

642000

COVERED LH SEAT BACK INNER GUARDING STRUCTURE

17

642365

COVERED LH SEAT BACK OUTER GUARDING STRUCTURE

18

639295

SEAT BACK REAR POCKET

19

642383

LH SAFETY BELT SLIDE COVERING

20

63997600

LH SAFETY BELT SLIDE STRUCTURE

21

64760400

SAFETY BELTS (complete set)

22

63970700

L.H. SEAT BACK BELT-SLIDING

23

63691200

SCREW

24

64601900

LH CUSHION-SEAT BACK CONNECTING INNER PLATE

25

64601700

LH CUSHION-SEAT BACK CONNECTING INNER PLATE

26

62739200

LH DEVICE FOR BACK SEAT ADJUSTMENT

27

63294300

JOINTS CONNECTION

28

14302931

SCREW

85

160920

WASHER

30

13578305

WASHER

31

62651900

SEAT BACK RETURNING SPRING

32

62652000

SPRING RETAINING BUSH

33

62955800

CLAMP FOR L.H. SEAT BACK

34

64235900

PLATE FOR SEAT BACK FASTENING

53

40294308

SCREW

46

12601374

Washer

37

62752500

BUSHING

38

63998600

L.H. HANDLE FOR SEAT RELEASE

39

14358927

SCREW

40

149951

WASHER

41

64618600

ELECTRIFIED GUIDE ASSEMBLY

42

64977600

ELECTRIC MOTOR

43

64977700

SCREW

44

64978000

BOWDEN

45

14306374

SCREW

47

13550405

WASHER

48

64612800

UNDERGUIDE SHIM

49

64977800

UNION

50

64977900

SCREW

56

63395300

ELASTIC PLATE

54

63929800

SCREW

55

13028734

SCREW

57

63602900

ARTICULATED JOINTS TRANSMISSION COVER

78

14302374

SCREW

63

62823200

WASHER

62

64314300

SCREW

64

63622700

SCREW

65

12606876

WASHER

66

64491700

L.H. SEAT TOOTHED WHEEL

67

63622800

SCREW

68

64490300

L.H. SEAT HOOK LEVER

72

12642805

WASHER

71

64490200

RH HOOK LIFTING LEVERAGE

74

14440521

SCREW

75

64490700

SPACER

76

64242800

R.H. HOOK FOR SEAT

77

64490600

SPACER

81

11087576

Snap Ring

80

64490800

PIN

82

64490400

SPRING

83

64491500

COMPLETE SMALL PISTON

84

63622600

SCREW

86

64978200

STOP RING

87

64978100

SHAFT

88

64978300

POTENTIOMETER

89

64978500

WASHER

90

64978400

SCREW

91

64978600

FIXING BUTTON FOR CABLES

92

167924

JUMPER FOR RELAY

93

64763100

STRIKER ON PASSENGER SEAT

94

15915877

SCREW

95

166935

CLIP
