No

Kod

Parça Adı

-

180319

GASKET

-

223707

GASKET

-

161021

UNION

7

178061

UNION-TANK CONNECTING PIPE

9

180320

COPMLETE TANK PLUG

-

226444

COMPLETE PLUG

1

186167

FUEL TANK

2

168238

COMPLETE FUEL LEVEL INDICATOR CONTROL

3

121435

RING NUT

4

160777

COUNTER FLANGE

5

160774

UNION

6

160778

GASKET

8

13000790

Screw Collar

10

180585

GASKET FOR PLUG

11

13276470

SCREW

12

11197774

Washer

13

147246

VENT PIPE FROM TANK TO

14

13432870

COLLAR FOR HOSE UNION

15

174472

VENT PIPE

16

262109

COLLAR

17

10441690

BRACKET WITH SHEATH

18

14039614

NUT

19

158345

FUEL TANK FASTENER

20

213177

THREADED TIE-ROD

24

264555

SPLIT PIN

22

103447

PIN

23

104030

Nut

25

156679

RUBBER THICKNESS

26

156680

RUBBER THICKNESS

27

159146

RUBBER THICKNESS

28

156682

RUBBER THICKNESS

29

159147

RUBBER SHIM

30

157411

RUBBER THICKNESS

31

157412

RUBBER THICKNESS

32

63939100

LOWER SHIELD

33

63965800

CAP

34

155887

FIXING CLIP

35

148045

FUEL DRAIN PLUG

36

123622

GASKET

37

142106

GASKET

38

62943200

RUBBER PROTECTION

39

65774200

NUT WITH CAGE

40

12648978

WASHER

41

16286127

SCREW

42

64337500

FRONT RH HEAT PROTECTION SHIELD

43

319201

FUEL FILLER PIPE ASSEMBLY

44

12638124

Washer

45

64337700

REAR RH HEAT PROTECTION SHIELD

46

64337600

FRONT LH HEAT PROTECTION SHIELD

47

64337800

REAR LH HEAT PROTECTION SHIELD

48

65460500

SHIELD FOR TANK PROTECTION

49

154802

GASKET

50

190154

COMPLETE RING -Valid for EU GS not F1 and

51

186172

CLIP
