No

Kod

Parça Adı

1

183826

FUEL TANK

2

168238

COMPLETE FUEL LEVEL INDICATOR CONTROL

3

121435

RING NUT

4

182049

FUEL DISAREATOR

5

182050

UNION

6

182403

GASKET

7

180498

UNION-TANK CONNECTING PIPE

8

10718670

Collar

9

226448

COMPLETE PLUG

10

223707

GASKET

11

13274472

SCREW -M5 X 20- -For carbon fibre surround-

12

12601174

Washer

13

182397

VAPOR EXHAUST PIPE

14

13432070

Collar for Hose Union

15

193286

WATER EXHAUST TUBE

16

13126170

CLAMP

17

291225

BRACKET WITH SHEATH

59

14039614

NUT

19

181365

FUEL TANK FASTENER

20

213177

THREADED TIE-ROD

24

264555

SPLIT PIN

22

103447

PIN

23

104030

Nut

25

156679

RUBBER THICKNESS

26

156680

RUBBER THICKNESS

27

159146

RUBBER THICKNESS

28

156682

RUBBER THICKNESS

29

159147

RUBBER SHIM

30

157411

RUBBER THICKNESS

31

157412

RUBBER THICKNESS

32

65971000

LOWER SHIELD

33

63965800

CAP

34

125769

Water Temperature Transmitter

35

148045

FUEL DRAIN PLUG

36

123622

GASKET

37

179321

GASKET

38

62943200

RUBBER PROTECTION

39

65774200

NUT WITH CAGE

40

12648978

WASHER

41

16286127

SCREW

42

64337500

FRONT RH HEAT PROTECTION SHIELD

63

319201

FUEL FILLER PIPE ASSEMBLY

44

12638124

Washer

45

64337700

REAR RH HEAT PROTECTION SHIELD

46

64337600

FRONT LH HEAT PROTECTION SHIELD

47

64337800

REAR LH HEAT PROTECTION SHIELD

48

65460500

SHIELD FOR TANK PROTECTION

49

154802

GASKET

50

10977524

SCREW

51

127494

Washer

52

12643724

WASHER

53

181180

R.H. VALVE

54

181183

L.H. FLOAT VALVE

55

195049

Gasket

56

66212600

REINFORCEMENT BRACKET

57

184274

THICKNESS

58

184275

THICKNESS

60

14496429

Washer

61

14622387

CAP

62

184206

GROUND CABLE

64

12637824

WASHER
