No

Kod

Parça Adı

1

265668

WATER PIPE

2

251271

RUBBER CONNECTOR PIPE TO RH SIDE RADIATORS

3

251273

RUBBER CONNECTOR PIPE TO LH SIDE RADIATORS

4

262473

RUBBER PIPE

4

237511

RUBBER PIPE

5

296781

SCREW COLLAR

6

267276

VENT PIPE

7

262478

PIPE

8

265889

WATER DELIVERY PIPE

11

10441290

BRACKET WITH SHEATH

10

231617

Screw

12

269286

WATER RETURN PIPE

13

808986

RING CLAMP

14

263067

COMPL. PILLORY BLOCK -Applicable from Ass. No. 90802 for EU Ihd- -Applicable from Ass. No. 91119 for Gulf -

14

264833

COMPL. PILLORY BLOCK -Applicable from Ass. No. 90802 for EU Ihd- -Applicable from Ass. No.91119 for Gulf-

15

270265

RH Water Radiator

16

262837

LH Water Radiator

17

275044

RH ELECTRIC FAN

18

13126970

COLLAR

19

82243300

POWER STEERING FLUID RADIATOR

20

262505

POWER STEERING FLUID RADIATOR PIPES

21

262836

Condenser

22

82911000

Lower RH Duct

23

82910900

Lower LH Duct

24

16285224

Screw

25

83240100

UPPER RH DUCT, LOWER SECTION

26

83240300

UPPER LH DUCT, LOWER SECTION

27

82745100

UPPER RH DUCT, UPPER SECTION

28

82745800

UPPER LH DUCT, UPPER SECTION

29

13833614

SCREW

30

258919

CLIP

31

231620

Screw

32

11566524

Screw

33

14058419

NUT

34

237478

Mounting

35

16287734

Screw

36

247751

Washer

37

10261460

Gasket

38

269646

UNION WITH BLEEDER

39

152954

BLEED SCREW

40

270388

WATER OUTLET UNION

41

10263460

Gasket

42

270450

BRACKET

43

11568124

SCREW

43

16286121

SCREW

44

61712500

Bracket with Sheath

45

231627

SCREW

46

10450690

BRACKET WITH SHEATH

47

269652

EXTENSION STUD -Height 60 mm

48

269651

EXTENSION STUD -Height 35 mm

49

268985

WATER DELIVERY PIPE

50

268986

WATER RETURN PIPE

51

184727

CONNECTOR
