No

Kod

Parça Adı

1

316565

COMPL. TUNNEL

1

308113

COMPL. TUNNEL

2

305372

COMPL. RH HALF FLOOR PANEL

3

305368

COMPL. LH HALF FLOOR PANEL

4

300620

RH CENTRE SIDEWALL

4

319018

RH CENTRE SIDEWALL

5

300619

LH CENTRE SIDEWALL

5

319016

LH CENTRE SIDEWALL

6

300798

SILL LINK CROSS MEMBER

7

83814500

FRONT RH ENDPIECE

8

83814600

FRONT LH ENDPIECE

9

83815000

REAR RH ENDPIECE

10

83814700

REAR LH ENDPIECE

11

272633

COMPL. UPPER RH HINGE REINFORCEMENT

12

272632

COMPL. UPPER LH HINGE REINFORCEMENT

13

271953

COMPL. LOWER RH HINGE REINFORCEMENT

14

271951

COMPL. LOWER LH HINGE REINFORCEMENT

15

290920

REAR FASTENER BRACKET FOR LH SEAT

15

290921

REAR FASTENER BRACKET FOR RH SEAT

16

262866

LH SEAT GUIDE RAIL FASTENER BRACKET

16

262867

RH SEAT GUIDE RAIL FASTENER BRACKET

17

283681

ACCELERATOR PEDAL FASTENER BRACKET

17

266326

ACCELERATOR PEDAL FASTENER BRACKET

18

300796

RH CONNECTOR PIECE EXTRUSION

19

300794

LH CONNECTOR PIECE EXTRUSION

20

86674700

LH LOWER FASTENER BRACKET FOR FRONT FENDER

21

86675900

A PILLAR FLANGE, FRONT RH ELEMENT

22

86675800

A PILLAR FLANGE, FRONT LH SECTION

23

86744400

RH LOCK STRIKER REINFORCEMENT

24

86744200

LH LOCK STRIKER REINFORCEMENT

25

312054

REAR FIREWALL

26

304741

RH INTERNAL BOX MEMBER ON REMOVABLE SUBFRAME

27

304740

LH INTERNAL BOX MEMBER ON REMOVABLE SUBFRAME

28

300646

RH UPPER REAR DIAGONAL BRACE

29

300645

LH UPPER REAR DIAGONAL BRACE

30

309294

RH SUSPENSION CASTING BRACE

31

309293

LH SUSPENSION CASTING BRACE

32

300903

RH B-PILLAR TRUSS

32

318911

RH B-PILLAR TRUSS

33

300901

LH B-PILLAR TRUSS

33

318909

LH B-PILLAR TRUSS

34

303064

RH FLOOR LATERAL EXTRUSION

35

303062

LH FLOOR LATERAL EXTRUSION

36

317833

RH SUBFRAME CONNECTOR CRASH BOX

37

317829

LH SUBFRAME CONNECTOR CRASH BOX

38

311870

BRACE EXTRUSION BETWEEN TORQUE BOX AND RH TUNNEL

38

316704

BRACE EXTRUSION BETWEEN TORQUE BOX AND RH TUNNEL

39

318360

BRACE EXTRUSION BETWEEN TORQUE BOX AND LH TUNNEL

39

311865

BRACE EXTRUSION BETWEEN TORQUE BOX AND LH TUNNEL

40

301625

RH CASTING LINK FRONT CROSS MEMBER

41

301624

LH CASTING LINK FRONT CROSS MEMBER

41

318355

FRONT LH CASTING LINK CROSS MEMBER

42

307806

LOWER RH DIAGONAL BRACE CONNECTED TO TUNNEL

43

307805

LOWER LH DIAGONAL BRACE CONNECTED TO TUNNEL

44

304362

FUEL TANK CROSS MEMBER

45

318915

RH TUNNEL UPPER FRONT DIAGONAL BRACE

45

307878

RH UPPER FRONT DIAGONAL BRACE FOR TUNNEL

46

307882

LH UPPER FRONT DIAGONAL BRACE FOR TUNNEL

46

318913

LH TUNNEL UPPER FRONT DIAGONAL BRACE

47

308659

REAR PILLAR BRACE FOR RH DOOR

48

306367

REAR PILLAR BRACE FOR LH DOOR

49

308762

RH A-PILLAR TRUSS

50

308761

LH A-PILLAR TRUSS

51

304706

UPPER RH BELT JOINT CASTING

52

304705

UPPER LH BELT JOINT CASTING

53

248977

FRONT RH FLOOR ENDPIECE

54

248976

FRONT LH FLOOR ENDPIECE

55

317392

INTERNAL TUNNEL REINFORCEMENT

56

300895

RH LOWER FRONT SUSPENSION CROSS-MEMBER REINFORCEMENT

57

300894

LH LOWER FRONT SUSPENSION CROSS-MEMBER REINFORCEMENT

58

304405

FRONT BRACKET FASTENING RH REAR FLANK TO CHASSIS

59

304404

FRONT BRACKET FASTENING LH REAR FLANK TO CHASSIS

60

313288

RH BODYSHELL SUBFRAME MOUNTING BRACKET

61

313286

LH BODYSHELL SUBFRAME MOUNTING BRACKET

62

311385

RH FUEL PIPE GUARD PLATE

63

311384

LH FUEL PIPE GUARD PLATE

64

87546300

COMPL. ENGINE BUFFER

65

13027024

SCREW

66

10523401

WASHER

67

322620

RH SKILLET MOUNTING BRACKET

68

322828

LH SKILLET MOUNTING BRACKET
