No

Kod

Parça Adı

1

36A 805 594 A

front frame, D >> - MJ 2017

1

36A805594C

front frame, D - MJ 2018>>

2

36A 805 113 C

side member, D >> - MJ 2017

2

36A 805 113 A

side member, D - MJ 2018>>

3

36A 805 114 C

side member, D >> - MJ 2017

3

36A 805 114 A

side member, D - MJ 2018>>

4

36A 805 201 A

mounting, for radiator, D >> - MJ 2017

4

4M0 805 201

mounting, for radiator, D - MJ 2018>>

5

36A 805 202 A

mounting, for radiator, D >> - MJ 2017

5

4M0 805 202

mounting, for radiator, D - MJ 2018>>

6

36A805511B

Bracket for charge air cooler

7

36A805512B

Bracket for charge air cooler

8

36A 805 307

filler plate

9

36A 805 308

filler plate

11

N91042302

oval hexagon socket head bolt

12

8K0 805 399 B

Hexagon socket head panel bolt

13

N 912 282 01

Hex socket head bolt (combi)

14

N 911 964 02

screw, hex. hd.

15

4M0 801 939

bracket

15

4M0 801 940

bracket

16

4M0802037B

side member

16

4M0802038C

side member

17

N 912 151 01

bolt, with polygon socket hd., (combi.), D - 31.07.2017>>

18

4M0 804 285

bracket

18

4M0 804 286

bracket

19

4M0 804 051

reinforcement

20

N 104 114 02

Hexagon socket oval head bolt, (combi)

21

N 910 717 02

Hexagon socket flat, head bolt, D >> - 20.01.2017

22

N 909 936 03

Hex socket head bolt (combi)

23

N 911 860 01

bolt, hex. hd. with shoulder,, self-locking

24

36A 807 233 A

end plate

27

36A 805 232 A

cross reinforcement

28

N 911 835 01

Hexagon socket head, bolt (combi)

29

N 011 670 31

support washer

30

N 910 968 01

Hexagon socket flat, head bolt

31

4M0802277B

bracket

31

4M0802278B

bracket

33

N 105 767 02

bolt, hex. hd. (combi.)

34

8H0806221

compensating piece

35

3R0 807 381

support part
