No

Kod

Parça Adı

-

11201-47081

Cover Sub-Assy, Cylinder Head

-

15330-47010

Valve Assy, Camshaft Timing Oil Control, No.1

-

90119-07009

Bolt, Camshaft housing Set, No.1

-

11123-31041

Bush, Exhaust Valve Guide, O/S 0.05

-

11131-47010

Seat, Intake Valve, STD

-

11136-47010

Seat, Exhaust Valve, O/S 0,03

1

11201-47080

Cover Sub-Assy, Cylinder Head

2

11213-47020

Gasket, Cylinder Head Cover

3

12180-38010

Cap Sub-Assy, Oil Filler

4

90430-35001

Gasket, Oil Filler Cap

5

90919-05060

Sensor, Crank Position, No.1

11

91551-80635

Bolt, Head to Camshaft Bearing Cap

7

15330-47020

Valve Assy, Camshaft Timing Oil Control, No.2

8

90099-14137

O Ring, Cam Timing Oil Control Valve

9

91671-80614

Bolt, Flange with Washer

10

90109-06384

Bolt J807

12

90201-06047

Washer, Plate

13

90210-12011

Washer, Seal, Cylinder Head Cover

14

11103-47010

Housing Sub-Assy, Camshaft

15

90253-13005

Pin, Ring, Camshaft Bearing Cap Setting

18

90105-08455

Bolt, Camshaft housing Set, No.2

17

11159-47010

Gasket, Camshaft Bearing Cap Oil Hole

19

91671-G0835

Bolt, Flange

20

11101-49465

Head Sub-Assy, Cylinder

21

90253-11004

Pin, Ring with Head

23

11122-31041

Bush, Exhaust Valve Guide, STD

24

11132-47010

Seat, Intake Valve, O/S 0,03

25

11135-47010

Seat, Exhaust Valve, STD

26

12281-47022

Hanger, Engine, No.1

27

12282-47010

Hanger, Engine, No.2

28

91552-81040

Bolt, Flange, V106

29

90126-06002

Stud, Hex Lobular

30

11115-47050

Gasket, Cylinder Head

31

90910-02174

Bolt, Cylinder Head Set

32

90201-10344

Washer, Plate, Cylinder head Set

33

90126-08063

Bolt, Stud, Exhaust Manifold to Cylinder Head
