No

Kod

Parça Adı

1

64-140080-AA

Bonnet assy, Zagato

1

64125117AA

Bonnet assy, V12, spares

1

64-125267-AB

BONNET ASSEMBLY GT

1

64-121941-AB

BONNET ASSEMBLY-V12

2

64-84536

ASSY STRIKER-BONNET

3

700606

Screw, M6 x 12, Hex Flange Head

4

64-80766

BONNET HINGE ASSY

5

697728

SCREW-S/STEEL

6

FD43-E830667-AA-PK

Washer 25mm x 6.4mm-10

46

697807

Screw, hex hd M8 x 16 - black

8

695652

WASHER M8 SPRING

9

697806

Washer, plain, M8 large 0D

10

64-124014-AA

GAS STRUT BONNET

11

1R12-640101-AA

Ball Stud

12

85-121478-AD

BONNET LINER

13

85-82503-PK

FIRTREE FASTENER(20)

14

64-83162

HOOK-BONNET S/CATCH

15

64-82482

BRACKET-BONNET SAFETY CATCH

16

697632

SCREW-M6 x 30 FLG

17

64-82483

PIVOT PIN SAFETY CATCH

18

64-123942-AA

BEARING SPACER - BONNET HOOK

19

64-82489

SPRING SAFETY CATCH - BONNET

20

64-82490

CLIP SAFETY 3/16inSHAFT

21

64-82487

BRACKET SAFETY CATCH

22

699106

SCREW M4 x 10 HEX SOCKET

23

697431

NUT M4 NYLOC

24

78-122232-AA

PANEL - ENGINE BAY RH RHD

25

78-123455-AA

PANEL-ENGINE BAY LH LHD MANUAL

25

78-122233-AA

PANEL - ENGINE BAY LH RHD

25

78-122230-AA

PANEL - ENGINE BAY RH LHD

25

78-122231-AA

PANEL - ENGINE BAY LH LHD

25

41-80153

BUFFER

26

699107

STUD-DZUS

27

697669

FASTENER RECEPTACLE DZUS 336 200 190

30

698987

SCREW FLG M10x20 BTN SKT HD

29

697578

SCREW M10 x 25 FLANGE TORX

31

697258

WASHER M10 PLAIN FORM A

32

697406

WASHER M10 SPRING

33

697322

NUT M10 HEX

34

64-86197

LEVER-BONNET RELEASE

35

64-82492

BRACKET HANDLE RELEASE

36

697320

SCREW M5 x 12 HEX FLANGE HEAD GRADE 8.8

37

697118

SCREW M5 x 16 HEX FLANGE HEAD GRD 8.8 ZINC PLATE

38

64-82500

CABLE BONNET RELEASE

39

64-82498

Assy Sleeve Cable LH

40

64-82501

Grommet

40

37-90075

Cable Tie, 290mm

41

64-82499

Assy Sleeve Cable LH to RH

42

64-82493

ASSY LATCH - BONNET

43

64-82497

BRKT-CABLE END

44

64-83192

BONNET LATCH MTG BRACKET RH

44

64-83193

BONNET LATCH MTG BRACKET LH

45

64-82494

PLATE LATCH FIXING

47

697516-PK

NUT-M6 HEX BLK (10)

48

77-90054

SEAL - BONNET REAR

49

77-83284

SEAL-SIDE BONNET

50

83-83563

ASSY-RETAINER WEATHERSTRIP RH

50

83-83564

ASSY-RETAINER WEATHERSTRIP LH

50

64-125312-AB

BONNET VENT GRILLE RH GT

50

64-125311-AB

BONNET VENT GRILLE LH GT

50

77-83393

SEAL ASSY- BONNET FRONT

50

64-82485

PLUG
