No

Kod

Parça Adı

23

34-122238-AA

HOSE ASSY - EVAP FLANGE TO CARBON CAN (NON FED)

1

34-120888-AB

BRACKET ASSEMBLY- CANISTER MOUNTING RH

2

34-121367-AB

BRACKET-ASSEMBLY CANISTER MOUNTING LH

3

34-85176

FOAM STRIP-40mm

4

34-84916

CARBON CANNISTER

5

34-84258

GROMMET - RUBBER

6

34122237AA

T connector

7

34-121557-AA

PIPE ASSY VACUUM

8

34-122239-AA

HOSE ASSY - EVAP FLANGE TO CARBON CAN (FED)

9

34122240AA

T connector

10

34123178AA

Hose, 90 long

11

34-85178

SENSOR-FTPT-REMOTE

22

34122242AA

Clip

13

34122250AA

Hose, 475 long

14

34122243AA

Elbow connector

15

34122990AA

Schraeder valve assy

16

34122252AA

Hose, 70 long

17

34122286AA

Clip

18

34122244AA

Pipe, canister to canister

19

34-122994-AA

HOSE

30

34122995AA

Hose, 60 long

21

34-85325

CONNECTOR-C/CANISTER

24

34-122754-BA

HOSE TANK TO FILLER NECK (CONV)

24

34-122704-AA

HOSE TANK FILLER NECK (COUPE)

24

698996

CLIP PIPE DIA 15-21

25

34-85308

STANT GRADE VALVE

26

34-84269

PURGE VALVE (CANVNT)

27

34-84268

PURGE VALVE (VMV)

28

34-123472-AA

ASSEMBLY-BRACKET-RH CANISTER RETAINER

29

34-123470-AA

ASSEMBLY-BRACKET-LH CANISTER RETAINER

30

34-122971-AB

PIPE - SOLENOID TO FIRST CAN

30

34122996AA

Hose

30

34-85533

FOAM PAD

30

697304

SCREW M5 x 10 HEX FLANGE HEAD GRADE 8.8

31

32-81332

GROMMET- 12.7 Dia 2.8 P.T

32

34-121263-AB

PIPE SIGNAL - UNDER FLOOR

32

34-84539

ARMOUR HOSE

32

700119

SPACER

32

37-90075

Cable Tie, 290mm
