No

Kod

Parça Adı

0

60-121914-BA

ASSY TONNEAU PANEL RH-DB7 V12 VOLANTE

1

60-121913-BA

ASSY TONNEAU PANEL LH-DB7 V12 VOLANTE

2

61-83718

ASSY RR QTR INNER COMPLETE RH

3

61-83719

ASSY REAR QTR INNER COMPLETE LH

4

6180698

Nut plate, door latch striker

6

21122297BC

Fuel filler box, lower

5

21122423BC

Fuel filler box, lower

6

21140642AA

Fuel filler box assy, outer

6

21121963BA

Fuel filler box, outer

7

67-83685

ASSY BOOTLID HINGE

8

60121910AA

Panel, tonneau extension RH

8

67-83684

GASKET-BOOTLID HINGE

9

60121909AA

Panel, tonneau extension LH

11

61-85650

ASY-PNL TONN/SILL-RH

10

78-140490-AA

FOAM STRIP - TONNEAU TO SILL RH

10

78-140491-AA

FOAM STRIP - TONNEAU TO SILL LH

10

61-85651

ASY-PNL TONN/SILL-LH

11

61-83713

EXTN SEAL FLANGE LWR RH

12

61-83714

EXTN SEAL FLANGE LWR LH

12

22-82949

ASSY REAR LONGIT EXTN RH

12

21-110856-BA

ASSY - REAR LONGIT RH

13

21-110857-BA

ASSY - REAR LONGIT LH

14

22-82950

ASSY REAR LONGIT EXTN LH

15

22-80666

ASSY-XMBR BUMPER MOUNTING REAR

16

21-110848-BA

ASSY-BOOT FLOOR (CONV)

16

2112922AA

Sub assy, luggage floor rear

16

22-80596

PANEL WHEELARCH OUTER RH

17

22-80597

PANEL WHEELARCH OUTER LH

18

61-80702

PANEL CLSG LIGHT BOX UPPER RH

18

60121919BA

Panel, rear deckrail - outer

19

61-80704

PNL CLSG LIGHT BOX UPPR OUTER-RH

19

61-80703

PANEL CLSG LIGHT BOX UPPER LH

20

61-80705

PNL CLSG LIGHT BOX UPPR OUTER-LH

20

61-80706

PANEL CLOSING LIGHT BOX RH

21

61-80707

PANEL CLOSING LIGHT BOX LH

21

61-83693

S/A PNL DRAIN CHNL RH

22

22-80755

REINF BRKT BUMPER MTG REAR RH

22

61-83694

S/A PNL DRAIN CHNL LH

23

22-80756

REINF BRKT BUMPER MTG REAR LH

23

22-80757

EXTN BOOT FLOOR RH

23

80-90326

WATER DEFLECTOR

24

22-80592

PANEL CLSG-LUGGAGE FLOOR SIDE-RH

24

22-80758

EXTN BOOT FLOOR LH

25

22-80593

PANEL CLSG-LUGGAGE FLOOR SIDE-LH

25

61-82947

ASSEMBLY BODY REAR LOWER

27

61-82948

ASSY TAIL LAMP X-MEMBER

32

61-83727

ASSY BRACE TONNU TO W/ARCH RH

33

74125104AA

Bracket assy, child seat outer, RH

33

74125105AA

Bracket assy, child seat outer, LH

33

18-123871-AA

ASSY RETAINING PLATE SPARE WHEEL

33

74124937AA

Bracket assy, child seat inner

33

700892

Screw, torx pan, M6 x 12

33

60-140620-AA

PANEL TONNEAU TO EXTENSION PANEL LUGGAGE FLOOR RH

33

60-140621-AA

PANEL TONNEAU TO EXTN PANEL LUGGAGE FLOOR LH

33

60140630AA

Reinforcement, sidemember, rear part, rear, RH

33

60140631AA

Reinforcement, sidemember, rear part, rear, LH

33

60-140624-AA

PANEL CLOSING BODYSIDE PANEL ON CHASSIS RH

33

60-140625-AA

PANEL CLOSING BODYSIDE PANEL ON CHASSIS LH

33

60-140618-AA

PANEL REAR QUARTER INNER EXTENSION RH

33

60-140619-AA

PANEL REAR QUARTER INNER EXTENSION LH

33

60-140626-AA

NUT ASSEMBLY PLATE ON SUPPORT EXHAUST RH

33

60-140627-AA

NUT ASSEMBLY PLATE ON SUPPORT EXHAUST LH

33

60-140648-AA

NUT ASSEMBLY BRACKET SUPPORT REAR BUMPER

33

60-140622-AA

Panel, bodyside closing on chassis, RH

33

60-140623-AA

Panel, bodyside closing on chassis, LH

33

60-140616-AA

PANEL REINFORCEMENT PANEL INNER RH

33

60-140224-AA

PANEL REAR TRUNK WATERWAY LOWER

33

60140226AA

Bodyside assy, rear end complete

33

60-140217-AA

Panel, rear wheel arch outer, LH

33

60-140216-AA

Panel, rear wheelarch outer, RH

33

60140222AA

Panel, rear trunk waterway, RH

33

60140223AA

Panel, rear trunk waterway, LH

33

60-140220-AA

PANEL REAR LAMP MOUNTING RH

33

60-140221-AA

PANEL REAR LAMP MOUNTING LH

33

60140646AA

Reinforcement, door lock, RH

33

60140647AA

Reinforcement, door lock, LH

33

60-140225-AA

PANEL REAR TONNEAU UPPER

33

60140632AA

Rocker panel, joining, RH

33

60140633AA

Rocker panel, joining, LH

33

60140218AA

Panel, bodyside rear RH

33

60140219AA

Panel, bodyside rear LH

33

60140643AA

Bracket, aerial support

33

60-140211-AA

ASSEMBLY REAR PARCEL SHELF

33

60-140649-AA

STUD ASSEMBLY REINFORCEMENT HINGE

33

60-140634-AA

STUD ASSEMBLY COLLAR RH

33

60-140635-AA

STUD ASSEMBLY COLLAR LH

33

60-140636-AA

END PLATE RH

33

60-140637-AA

END PLATE LH

33

61-83728

ASSY BRACE TONNU TO W/ARCH LH

33

18-90380

ASSY-REAR JACK PLATE -RH

33

18-90381

ASSY-REAR JACK PLATE -LH

33

78-124721-AA

SCREW 3/8 UNF CSK S/STEEL

33

21-86002

SPACER-JACKING POINT
