No

Kod

Parça Adı

1

93-110874-BAW

ASSEMBLY - COMPLETE CONVERTIBLE HOOD

1

93-100529-BAW

ASSY COVER (MOHAIR) OUTER

1

93-89695

TENSION WIRE ASSY RR

2

88-111770-BAW

TONNEAU COVER -HAARTZ TWILLFAST II

2

88-123912-BAW

TONNEAU COVER - LEATHER/PIPED

2

88-111772-BAW

TONNEAU COVER -EVERFLEX

2

88-111771-BAW

TONNEAU COVER -LEATHER

3

012008

Calico

4

83140144ABW

Headlining assy, quilted

4

83140174ABW

Headlining assy, ribbed

4

93-100548-BAW

ASSY HOOD HEADLINING (ALCANTARA)

5

692205

POP-RIVET 1/8 x3/8

6

93-89749

WEBBING FIXING PLATE

8

696578

SCREW No6 x 1/2inCSK POZI GRD 4 8 ZINC PLT BLACK PASSIVATE

9

93-89513

RAIL RETAINING H/LINING RR CENTRE

10

93-89514

RAIL RETAINING H/LINING RR OUTER

11

93-89552

CAM ADJUSTER

12

697078

Screw, flg, M8 x 20

13

93-89748

ROD STRAP INSERT 70mm long

14

93-89670

WIRE TUBE TENSION

31

697066

POP RIVET 3-2X11

16

93-89671

SIDE TENSION WIRE ASSY

30

93-89669

WIRE SPRING TENSION

18

696652

End tip

19

93-89665

TENSION WIRE ASSY

20

93-89880

ASSY B/LIGHT SUPPORT BRACKET RH

20

93-89838

CAP SPRING WIRE TOP

21

93-89881

ASSY BACKLIGHT SUPPT BRACKET LH

22

699165

SCREW M6x12 CSK GED 4 8 BLACK CROSS RECS

23

93-89550

DEFLECTOR WIND REAR REWORK RH

23

700606

Screw, M6 x 12, Hex Flange Head

24

93-89551

DEFLECTOR WIND REAR REWORK LH

25

93-89548

DEFLECTOR WIND FRONT REWORK RH

33

698489

POP RIVET 3.2x6.35 ALUM DOMED - BLACK TAPD 44 BS

26

93-89549

DEFLECTOR WIND FRONT REWORK LH

27

93-89560

WIRE GUIDE TENSION RH

27

698490

POP RIVET -AL-DOMED 1/8x0.310 - BLACK DEFLECTORS

28

93-89561

WIRE GUIDE TENSION LH

29

630-000-0102

WASHER No6 PLAIN CHROME

31

93-89558

SPACE PLATE CANTRAIL RH

32

93-89559

SPACE PLATE CANTRAIL LH

33

93-89580

ASY CLOSING LATCH RH

34

93-89581

ASY CLOSING LATCH LH

35

93-89612

ASSY HANDLE CLOSING LATCH RH

35

692345

SCREW M5 x 10 CSK POZI M/C ZINC PLTD

36

93-89613

ASSY HANDLE CLOSING LATCH LH

37

93-89571

CIRCLIP (LATCH)

38

93-89543

PIN BEARING FRT SHORT

39

93-89554

HANDLE COVER REWORK RH

39

93-89555

HANDLE COVER REWORK LH

40

93-86253

PIVOT PIN

41

697080

SCREW M6x8 BTN FLG GRD 10 9 BLACK COVER TO LATCH

42

697436

SPEED NUT

43

695158

SCREW M6 x12 HEX FLG GRD 8.8 ZINC PLATED

44

93-89535

MOULDING ROOF FRONT

44

93-124876-BA

INSERT - REAR BOW RH

45

93-124877-BA

INSERT - REAR BOW LH

46

697079

SCREW NO 8x5/8 POZI BLACK PAN HEAD CLOSING LATCH COVER

47

9389502

Backlight assembly - volante

48

696042

Foam

49

83140153ABW

Header assy rear, trimmed, complete

49

83140158ABW

Cantrail assy, trimmed complete, RH

49

83140159ABW

Cantrail assy, trimmed complete, LH

49

83-140148-ABW

ASSEMBLY COMPLETE FRONT HEADER

49

83140151AAW

Trim panel, front header

49

83140128AAW

B post assy complete, RH

49

83140129AAW

B post assy complete, LH

49

83140136AAW

C post assy complete, RH

49

83140137AAW

C post assy complete, LH

49

83140155AAW

Trim panel, rear header

49

83140162AAW

Trim panel cantrail, RH

49

83140163AAW

Trim panel cantrail, LH

49

83140134AAW

Trim panel, B post, RH

49

83140135AAW

Trim panel, B post, LH

49

83140142AAW

Trim panel, C post, RH

49

83140143AAW

Trim panel, C post, LH

49

83-140149-AB

ASSEMBLY FRONT HEADER

49

83140154AB

Header assy, rear

49

83-140160-AB

CANTRAIL ASSEMBLY RH

49

83-140161-AB

CANTRAIL ASSEMBLY LH

49

83-140130-AA

ASSEMBLY B POST RH

49

83-140131-AA

ASSEMBLY B POST LH

49

83-140138-AA

ASSEMBLY C POST RH

49

83-140139-AA

ASSEMBLY C POST LH

49

697468

SCREW/WASHER No8 x19 PAN HD AB

49

1R12-834052-AA

PLATE - REINFORCED COAT HOOK

49

697571

NUT LOKUT

49

83-84823

SNAPSAC

49

1R12-834074-AAW

COAT HOOK - TRIMMED

49

700106

SCREW No6x13 S/TAPP

49

83-110940-AA

FIRTREE BUTTON

49

697648

Fastener, Fir Tree

49

697645

SCREW-SELF DRILLING

49

83124911BAW

Header rail, convertible

49

93-111432-BA

STUD-TONNEAU FIXING

49

698086

DURABLE DOT RIVET COMPLETE

49

93-125642-BA

TORSIONAL SPRING HOOD WIRE RH

49

93-125643-BA

TORSIOANAL SPRING HOOD WIRE LH

49

93-89837

SPRING WIRE

49

93-100592

EDGE RETAINER - SIDE SHORT RT ANGLE

49

93-89925

EDGE RETAINER REAR LONG
