No

Kod

Parça Adı

1

AD43-V17N800-AC

BUMPER FRONT CRASH CAN

52

703172-PK

Screw-M8x25 Pan 8 Chrome Free Pack of 10

2

703201

SCREW M8 x 30 HEX FLANGE CHROME FREE

3

4G43-13068-AD

PANEL HEADLAMP MOUNTING RH

4

4G43-13069-AD

PANEL HEADLAMP MOUNTING LH

5

4G43-6367912-AD

NUT PLT ASY FRT CRSH

6

4G43-043B19-AC

TUBE PASSENGER AIR BAG INITIATPR RH

7

4G43-043B20-AC

TUBE PASSENGER AIR BAG INITIATOR LH

8

4G43-108A86-AE

BRACKET FRONT CROSS BRACE RH

9

4G43-108A87-AE

BRACKET FRONT CROSS BRACE LH

10

4G43-108A75-AA

BRA FRT CS

13

702209

Bolt, M10 x 25, Torque Drive

12

4G43F00198AF

Reinforce, body cross bar, RH

12

4G43F00199AF

Reinforce, body cross bar, LH

30

703163

Nut, M6, Hex Flange Head, Locking

14

4G43-5340-AJ

BRACKET ECU MOUNTING RH

15

4G43-5341-AJ

BRACKET ECU MOUNTING LH

29

703203

Screw M6 x 20 Heex Flange 8 Chrome Free

17

4G43-16802-AA

NUT PLATE HOOD HINGE MOUNTING BRACKET

18

4G43-111C61-AE

Panel, Dummy Floor Front, RHD

18

4G43-111C60-AD

PANEL DUMMY FLOOR FRONT

19

4G43-111B48-AB

Panel, Dummy Floor Cover, Front

20

701553

Screw, M6 x 16, Pan Head

21

4G43-111K36-AF

TUNNEL REINFORCEMENT FRONT

22

4G43-111K37-AE

Tunnel Reinforcement, Centre

24

4G43-1660-AA

TUNNEL REINFORCEMENT FRONT SPACER

25

7G43-10N660-AC

PANEL BATTERY COVER RH

26

7G43-10N661-AA

PANEL BATTERY COVER LH

27

4G43-67518-AE

PANEL REAR SEAT HEEL BOARD RH

28

7G4367519AB

Panel, rear seat heel board LH

31

4G43-38580-AK

ASY PNL F/TNK COMP

47

703121

Screw, M8 x 25, Hex Flange Head

33

4G4318A000AC

Member, rear damper mnting RH

34

4G4318A001AC

Member, rear damper mnting LH

35

703185

M12x1.75x25 HEX FLANGE HEX HEAD CHROME FREE

36

4G43-L04702-AG

Cover panel, window reg opening, RH

36

8G43-L04702-GA

PANEL WINDOW REGULATOR OPENING COVER RH

36

4G43-L04703-AG

Cover panel, window reg opening, LH

36

8G43-L04703-GA

PANEL WINDOW REGULATOR OPENING COVER LH

37

9G43-28034-AB

Panel, Rear Quarter Shedder, RH

37

9G43-28035-AB

Panel, Rear Quarter Shedder, LH

38

4G43-303A92-AB

QTR WINDOW REG MNT BRKT RH

38

4G43-303A93-AB

QTR WINDOW REG MNT BRKT LH

39

4G43-14A573-AA

Plate Assembly, Window Regulator Rear Switch Cover

42

700607

Screw, M6 x 16mm, Hex Flange Head

41

4G43-A410K24-AH

Panel, Rear Body Pillar Closing, RH

41

4G43-A410K25-AH

Panel, Rear Body Pillar Closing, LH

43

7G43-10609E-AA-PK

Clip SPG M6 U Type 1.5-4.0 BLK Pack of 10

44

HY53-E804349-AA

M6 X 14 SCREW HEX HD

45

4G43-501B0-AC

NUT PLATE REAR SUB FRAME REAR M14

46

4G43-433A32-AF

REINF L/C DR LAT HSE

48

4G43-L243A70-AA

Alignment Pin, Main Bearing Bracket

49

703149

SCREW M6x16 PAN FLG TORX CHROME FRE

50

FD43-E830667-AA-PK

Washer 25mm x 6.4mm-10

51

4G43-11262-AC

REINF ASSY FRT FLR PAN FRT

51

9G43-11262-BA

Reinforcement Assembly, Floor Pan Front

52

703268

Screw and Washer, M8 x 21

53

6G33-FA0115-AB-PK

Screw and Washer, M6 x 20, Torx Head

54

4G43-2943707-AA

PLATE WELD NUT CENTRE
