No

Kod

Parça Adı

-

62612600

L.H. terminal

-

62389900

R.H. panel

-

62479400

R.H. panel

-

62845600

L.H. red protection

-

62732800

Front holder

-

62513200

R.H. bracket

-

62900200

L.H. side conveyor

-

62610800

R.H. air duct

-

62731800

Battery cover

5

62610900

L.H. air duct

-

62901100

Floor

1

62383800

Floor

2

60909500

Screw

3

12648925

WASHER

4

62506900

Battery cover

6

62900100

R.H. side conveyor

7

12637824

WASHER

8

63394400

Tube

9

319201

FUEL FILLER PIPE ASSEMBLY

10

82118300

SCREW -No longer supplied- -Replaced by 11625714-

11

62389300

Air central conveyor

12

62513300

L.H. bracket

13

10902224

SCREW

36

12643724

WASHER

15

11197774

Washer

16

62506800

Front holder -Not for

17

62302700

Plug

18

14039614

NUT

19

12640678

Washer

20

62845500

R.H. red protection

21

62493100

Gasket

22

14779611

SCREW

23

62472400

Front central grille

24

62479500

LH. panel

25

62390000

L.H. panel

26

62385300

Under board

27

62513600

Pin

31

62468000

Stop ring

32

62467900

Pin clip

30

62468100

Pin

33

16101772

Nut

34

12647701

WASHER

35

20037008

Spring

37

62561000

External shield

38

62561100

Internal shield

39

62572100

Plenum air filter

40

13270572

Screw

41

12639477

WASHER

42

10615176

Washer

43

62494900

Gasket

44

62612500

R.H. terminal

45

62901200

Front central grille

46

62900000

Air central conveyor
