No

Kod

Parça Adı

1

194700

HYDRAULIC TAPPET FOR VALVE

2

179763

COTTER FOR VALVE SPRING

3

187489

UPPER WASHER

4

184054

OUTER SPRING FOR VALVE RETURN

5

184055

INNER SPRING FOR VALVE RETURN

6

221473

OIL SEAL

7

204178

LOWER CUP

7

190408

LOWER CUP

8

6172452

INTAKE AND EXHAUST VALVE GUIDE

8

6213498

INTAKE AND EXHAUST VALVE GUIDE

9

6222847

INDUCTION VALVE SEAT

10

6222848

EXHAUST VALVE SEAT

11

198581

INTAKE VALVE

12

227334

EXHAUST VALVE

13

212825

RH INTAKE CAMSHAFT

14

212827

RH EXHAUST CAMSHAFT

15

212824

LH INTAKE CAMSHAFT

16

212826

LH EXHAUST CAMSHAFT

23

134701

O.R. GASKET

18

189541

VARIATOR OIL PUMP

19

184731

WASHER

20

14303523

SCREW

21

198668

PHASE VARIATOR MOUNTING BUSHING

22

214742

RING

24

10617520

TAB

25

193779

TIMING VARIATOR

26

189576

TOOTHED WHEEL

27

190163

VARIATOR OIL TANK

28

193738

THREADED UNION

29

10261060

GASKET

30

193406

Oil Accumulator Bracket

31

190162

CLAMP

32

194710

PIPE FROM ACCUMULATOR TO CYLINDERS HEADS

33

94077843

SCREW
