No

Kod

Parça Adı

1

3R12-835642-AAW

DOOR CASE RH TRIMMED

1

3R12-835643-AAW

DOOR CASE LH TRIMMED

1

1R12-831474-ABW

DOORCASE RH TRIMMED

1

1R12-831475-ABW

DOORCASE LH TRIMMED

1

3R12-835896-AAW

DOOR CASE RH TRIMMED

1

3R12-835897-AAW

DOOR CASE LH TRIMMED

2

1R12-830836-AAW

DOOR ARMREST RH TRIMMED

2

1R12-830837-AAW

DOOR ARMREST LH TRIMMED

2

3R12-835904-AAW

DOOR ARMREST RH TRIMMED

2

3R12-835905-AAW

DOOR ARMREST LH TRIMMED

3

697475

WASHER M5 PLAIN

3

694045

NUT M5 - WING GRD 4 ZINC PLT.

4

1R12-830832-AD

HANDLE - DOOR RH

4

1R12-830833-AD

HANDLE - DOOR LH

4

1R12-830832-AC

HANDLE - DOOR RH (PRE 2002MY)

4

1R12-830833-AC

HANDLE - DOOR LH (PRE 2002MY)

4

1R12-834646-AB

HANDLE DOOR RH

4

1R12-834647-AB

HANDLE DOOR LH

5

692183

SCREW M6 x50 SCKT HD

6

1R12-834615-AA

SCREW M6x30 A2 S/STEEL SKT HD CAP SCREW TO DIN 912

7

1R12-830842-AC

HOUSING-LOWER - DOOR POCKET RH

7

1R12-830843-AC

HOUSING-LOWER - DOOR POCKET LH

7

3R12830842AA

Housing, lower, door pocket, RH

7

3R12-830843-AB

HOUSING-LOWER - DOOR POCKET LH

32

692314

NUT M4 x 0.7 SLK HEX HD GRD 8 ZINC PLT

9

1R12-831625-AC

MOUNTING BRACKET - DOOR TRIM

28

703278

Screw, M6 x 10, Flange Hex Head

11

699819

SCREW M6x25 SKT BUTTON FLANGE

11

700276

Screw, flg, M6 x 25

12

700226

WASHER PLAIN M6x17

13

1R12-834000-AB

MOUNTING BRACKET - DOOR TRIM UPPER RH

13

1R12-834001-AB

MOUNTING BRACKET - DOOR TRIM UPPER LH

14

698894

SCREW NO4 X 3/4 CSK HEAD POST TYPE BLACK

15

1R12-832089-AB

ESCUTCHEON INT. REL. HANDLE - PASS RHD

15

1R12-832088-AB

ESCUTCHEON INT. REL. HANDLE - PASS LHD

15

1R12-832086-AB

ESCUTCHEON INT. REL. HANDLE - DRIVER RHD

15

1R12-832087-AB

ESCUTCHEON INT. REL. HANDLE - DRIVER LHD

15

4R12-832089-AA

ESCUTCHEON INT. REL. HANDLE-PASS LH-RHD

15

4R12-832088-AA

ESCUTCHEON INT. REL. HANDLE-PASS RH-LHD

15

4R12-832086-AA

ESCUTCHEON INT. REL. HANDLE-DRIVER RH RHD

15

4R12-832087-AA

ESCUTCHEON INT. REL. HANDLE-DRIVER LH-LHD

16

699647

Screw, skt, M5 x 25

17

1R12-832090-AA

CLIP SWITCH RETAINING

37

77-84981-PK

Tape, Anti Rattle Rear Quarter Wheel

18

700275

SCREW 4.2x13 WSHR HD AB

19

1R12-831592-AA

HANDLE MOUNTING FRAME RH

19

1R12-831593-AA

HANDLE MOUNTING FRAME LH

21

1R12-831911-AD

SPACER - HANDLE FIXINGS

23

697516-PK

NUT-M6 HEX BLK (10)

24

700986-PK

Nut-M4 HEX FLG Pack of 20

24

1R12-381958-AB

BRACKET ASSY - DOOR MODULE RH

24

1R12-381959-AA

BRACKET ASSY - DOOR MODULE LH

26

1R12-370421-AA

BRACKET - DOOR SPEAKER

27

3R12-375701-AB

WATER SHEDDER - DOOR SPEAKER

27

6R13-375701-AB

WATER SHEDDER - DOOR SPEAKER

27

1R12-373560-AA

WATER SHEDDER - DOOR SPEAKER

29

1R12-831231-AA

FOAM SPEAKER SEAL

30

1R12-830855-AB

RING RETAINING - LOUD SPEAKER GRILLE

31

699118

NUT M3

32

3R12-835488-AB

ENCLOSURE DOOR SPEAKER

32

3R12-835489-AB

ENCLOSURE DOOR SPEAKER

32

3R12-835745-AA

RETAINING BRACKET SPEAKER GRILLE

32

3R12835647AA

Mounting ring assy, door speaker

32

3R12-835650-AA

FOAM ENCLOSURE DOOR SPEAKER

32

700106

SCREW No6x13 S/TAPP

32

1R12-831232-AC

MESH GRILLE

33

1R12-37-10693

MIRROR GLASS (EC)

33

37-85515

MIRROR GLASS-CONVEX

33

37-85514

MIRROR GLASS-FLAT

33

1R12-654742-AB

MIRROR ASSY RR VIEW EXT RH

33

1R12-654743-AB

MIRROR ASSY RR VIEW EXT LH

33

1R12-655708-AA

MIRROR ASSY REAR VIEW EXT RH AUSTRALI S/O 1R12-653760-**

33

1R12-655707-AA

MIRROR ASSY REAR VIEW EXT LH AUSTRALI S/O 1R12-653761-**

33

1R12-650149-AJ

MIRROR POD ASSY REAR VIEW EXTERIOR LH

33

1R12-653760-AC

MIRROR POD ASSY - REAR VIEW EXT POWER PARK RH

33

1R12-653761-AC

MIRROR POD ASSY - REAR VIEW EXT POWER PARK LH

33

1R12-654570-AB

MIRROR ASSY RR VIEW EXT RH

33

1R12-654571-AB

MIRROR ASSY RR VIEW EXT LH

33

1R12-651452-AF

MIRROR ASSY REAR VIEW EXTERIOR RH FEDERAL

33

1R12-651453-AF

MIRROR ASSY REAR VIEW EXTERIOR LH FEDERAL

33

37-85516

MIRROR GLASS-CONVEX USA

33

1R12654740AB

Mirror assy, rear view exterior, RH

33

1R12-650149-AH

MIRROR POD ASSY REAR VIEW EXTERIOR LH

33

1R12-650150-AJ

MIRROR POD ASSY REAR VIEW EXTERIOR RH

33

1R12651866AE

Mirror assy, rear view exterior, RH

33

1R12651867AE

Mirror assy, rear view exterior, LH

33

37-85512

MIRROR GLASS- CONVEX RH

33

37-85513

MIRROR GLASS- CONVEX LH

33

1R12-651226-AH

Foot assy, door mirror, RH

33

1R12-651227-AH

Foot assy, door mirror, LH

34

700134

WASHER

35

700255

SCREW

36

37-85543

MIRROR CAP-RH

36

37-85544

MIRROR CAP-LH

37

5R13-830912-BAW

ASSY-MIRROR PATCH TRIM COVER RH

37

5R13-830913-BAW

ASSY - MIRROR PATCH TRIM COVER LH

37

1R12-83-10556

Mirror Patch CVR Kit

37

1R12-83-10558

MIRROR PATCH CVR KIT

37

6R13-830912-AAW

ASSY-MIRROR PATCH TRIM COVER RH

38

1R12-372430-AB

ASSY BRACKET - HARNESS DOOR RH

38

1R12-372431-AB

ASSY BRACKET - HARNESS DOOR LH

39

703204

SCREW M5x16 HEX

40

703161

Nut Hex M8 Flange Chrome Free

41

1R12-780129-AD

WATERSHIELD - DOOR TRIM

42

1R12-373994-AA

EDGE PROTECTION - CUT LENGTH 260mm

43

1R12-37-10275

SWITCH PANEL- PASSENGERS DOOR

43

91929

SWTC PNL-DRIVER S DR

43

1R12-834618-ACW

ASSY INFILL PANEL - DOOR TRIM - REAR RH

43

1R12-834619-ACW

ASSY INFILL PANEL - DOOR TRIM REAR LH

43

1R12-784156-AC

WATER SHEDDER - DOOR INNER
