No

Kod

Parça Adı

1

1R12-104566-AE

ASSY FRONT BULKHEAD INSULATION RHD

1

1R12-104567-AE

ASSY FRONT BULKHEAD INSULATION LHD

12

41-84347

WASHER M8 x 25mm OD HARDENED

13

703739

Nut, M8, Hex Flange Head

2

1R12-104324-AD

ASSY REAR BULKHEAD INSULATION

3

91775

ASSY-TUNNEL INSULATN

4

5R13-5E209-AA

AERO CLOSER PANEL - FRONT

4

5R13-17F018-AA

WHEEL TAB RH

4

5R13-17F017-AA

WHEEL TAB-LH

4

1R12-181950-AH

AERO CLOSER PNL FRT

5

1R12-160589-AD

TUNNEL SHEAR PANEL

6

1R12-162658-AA

SPACER - TUNNEL SHEAR PANEL

7

700260

BOLT M8 x 40 HEX FLG HEAD GRD 10.9

7

699527

O RING (DOWTY - 2025084470)

8

1R12-862743-AE

DUCTING TUNNEL LH

8

1R12-862744-AE

DUCTING TUNNEL RH

9

1R12-104112-AB

PROTECTOR HEATSHIELD BULKHEAD FRONT

10

1R12-104113-AB

PROTECTOR HEATSHIELD BULKHEAD FRONT

11

1R12-632498-AE

HEATSHIELD-PLENUM RHD/LHD

12

703129

Washer Large OD M12 Chrome Free

14

1R12-104310-AA

PATCH - TUNNEL TO REAR BULKHEAD

15

1R12-162704-AA

SPACER-AERO PANEL

16

1R12105287AB

Service foam repair kit, tunnel insulation

16

1R12-105286-AB

SERVICE PATCH KIT TUNNEL INSULATION

16

699297

SCREW M4 X 16 FLAT CSK 8

16

700247

SCREW &WSHR M6x20

16

1R12-182014-AA

NUTPLATE AERO CLOSER PANEL

16

1R12104326AB

Self adhesive patch

17

1R12-224068-AB

ASSY - REINF REAR FRAME

17

703265

Screw, M6 x 16, Hex Flange Head
